New 2026 Ford Super Duty F-550 DRW 4WD CREW Cab Knapheide 12' Flatbed LARIAT Crew 179" WB 60" CA

Status: On Lot
VIN: 1FDSW5HT8TEE78737
Stock #: T0713

Vehicle Details

Trans.:Automatic
Engine:8 Cylinders
Drivetrain:Four Wheel Drive
Fuel Type:Diesel
Ext. Color:OXFORD WHT
Int. Color:MED DK SLATE HD VINYL 40/
Walker Price
$96,694
MSRP
$95,600
Internet Price
$96,694

Price includes all Dealer fees

people recently viewed this vehicle*

Description

Family owned and operated since 1957, Walker IS Ford.Price includes: $1094 – Doc Fee

Incentives

Standard Features

  • TIRES: 225/70RX19.5G BSW TRACTION – -inc: 4 traction tires on the rear and 2 A/P tires on the front
  • LIMITED SLIP w/4.30 AXLE RATIO
  • PLATFORM RUNNING BOARDS
  • Transfer case skid plates
  • SPARE TIRE & WHEEL – -inc: Excludes carrier, 6-Ton Hydraulic Jack
  • HIGH CAPACITY TRAILER Tow PACKAGE – -inc: trailer brake wiring kit, Increases GCW from 32,500 lbs, to 40,000 lbs, Note: Salesperson’s Portfolio or Trailer Towing Guide should be consulted for specific trailer towing or camper limits and corresponding required equipment, axle ratios and model availability, See Supplemental Reference for vehicle height consideration
  • Center high-mounted stop lamp (CHMSL)
  • 6-TON HYDRAULIC JACK
  • GVWR: 19,550 LB PAYLOAD PLUS UPGRADE PACKAGE 2
  • E: 6.7L 4V OHV PWR STROKE V8 T
  • TRANS: TORQSFT 10-SPD AUTO
  • LIC PL BRKT
  • RAPTOR-STY RUN BOARD
  • 50-ST EMIS
  • TLR BRK CNTLR
  • 40 GAL AFT OF AXLE FUEL TNK
  • UPF INTERFACE MOD
  • RR VIEW CAM/PREP KIT
  • ORDER CODE 660A
  • XL CHRM Pkg

Vehicle Location

Walker Ford Co Inc
17556 Us Highway 19 North
Clearwater, FL 33764

While every reasonable effort has been made to ensure the accuracy of the information contained on this website, absolute accuracy cannot be guaranteed. All vehicles are subject to prior sale. Vehicle pricing and availability are subject to change without notice.

Advertised prices include the dealership’s $995 dealer fee and $99 electronic filing fee. Advertised prices do not include applicable sales tax, title, registration, license, government fees, finance charges, or other fees required by law.

Sale prices include all applicable manufacturer rebates and incentives. Certain incentives, including Ford Credit bonus cash and other conditional offers, may require qualification and may not be available to all customers. Manufacturer incentives are subject to change without notice and may expire at any time.

Advertised pricing may not include dealer-installed accessories, aftermarket products, upfits, or value-added equipment added after publication. Any such items will be disclosed prior to sale.

Vehicle descriptions, specifications, features, equipment, pricing, and photographs are provided for informational purposes only and may contain errors or omissions. Pictures and descriptions are for illustration purposes only and may not reflect the actual vehicle offered for sale. Residency restrictions may apply. Advertised prices apply to in-stock vehicles only unless otherwise stated.



*Number of views in last 30 days

Send this listing to your phone by providing your phone number. We will not keep your information or send you additional texts.

  • By clicking send, I agree to send my information to Walker Ford and to get emails from Walker Ford. If I include my phone number, I agree to receive calls and text messages from Walker Ford (including automated). I can opt out at any time. This consent is not required as a condition of purchase. Message and data rates may apply. I also agree to the Walker Ford Privacy Notice & Policies , which explain how my data is used to personalize my experience.

  • This field is for validation purposes and should be left unchanged.

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Technical Specifications

  • Vehicle Name: Ford Super Duty F-550 DRW
  • Body Style: SD Crew Cab
  • Body Code: H
  • Drivetrain: Four Wheel Drive
  • Passenger Capacity: 5
  • Base Curb Weight: 7438, 7438, 8146
  • Gross Axle Wt Rating – Front: 5600, 6000, 6000, 6500, 6500, 6500, 7000, 7000, 7500, 7500
  • Gross Axle Wt Rating – Rear: 13660, 14706
  • Curb Weight – Front: 4209
  • Curb Weight – Rear: 3189
  • Gross Vehicle Weight Rating Cap: 17500, 18000, 19500, 19550
  • Gross Combined Wt Rating: 30000, 34500, 39000, 40000, 43000
  • Dead Weight Hitch – Max Trailer Wt.: 5000
  • Dead Weight Hitch – Max Tongue Wt.: 500
  • Wt Distributing Hitch – Max Trailer Wt.: 18500
  • Wt Distributing Hitch – Max Tongue Wt.: 1850
  • Fifth Wheel Hitch – Max Trailer Wt.: 21200, 24900, 29400, 33400
  • Fifth Wheel Hitch – Max Tongue Wt.: 5300, 6225, 7350, 8350
  • Maximum Trailering Capacity: 18500
  • Engine Order Code: 99T
  • Engine Type: Intercooled Turbo Diesel V-8
  • Displacement: 6.7 L/406
  • Fuel System: Diesel Direct Injection
  • SAE Net Horsepower @ RPM: 330 @ 2200
  • SAE Net Torque @ RPM: 950 @ 1800
  • Trans Order Code: 44G
  • Trans Type: 10
  • Trans Description Cont.: Automatic w/OD
  • Trans Description Cont. Again:
  • First Gear Ratio (:1): 4.62
  • Second Gear Ratio (:1): 2.92
  • Third Gear Ratio (:1): 2.13
  • Fourth Gear Ratio (:1): 1.77
  • Fifth Gear Ratio (:1): 1.52
  • Sixth Gear Ratio (:1): 1.28
  • Reverse Ratio (:1): 4.70
  • Trans Power Take Off: Yes
  • Trans PTO Access: Yes
  • Transfer Case Model: Electronic
  • Transfer Case Power Take Off: Yes
  • Cold Cranking Amps @ 0° F (Primary): 750
  • Cold Cranking Amps @ 0° F (2nd): 750
  • Maximum Alternator Capacity (amps): 190 & 160, 250 & 150, 250 & 160
  • Engine Oil Cooler: None
  • Suspension Type – Front: Other
  • Suspension Type – Rear: Leaf
  • Spring Capacity – Front: 5600, 6000, 6000, 6500, 6500, 6500, 7000, 7000, 7500, 7500
  • Spring Capacity – Rear: 13660, 14706
  • Axle Type – Front: Non-Independent
  • Axle Type – Rear: Rigid Axle
  • Axle Capacity – Front: 7000, 7500
  • Axle Capacity – Rear: 13660, 14706
  • Axle Ratio (:1) – Front: 4.10, 4.30, 4.88
  • Axle Ratio (:1) – Rear: 4.10, 4.30, 4.88
  • Front Tire Order Code: TGJ, TGK, TGM
  • Rear Tire Order Code: TGJ, TGK, TGM
  • Spare Tire Order Code: , 512
  • Front Tire Size: LT225/70SR19.5
  • Rear Tire Size: LT225/70SR19.5
  • Spare Tire Size: , Full-Size
  • Front Tire Capacity: 7500
  • Rear Tire Capacity: 15000
  • Revolutions/Mile @ 45 mph – Front: 645, 647
  • Revolutions/Mile @ 45 mph – Rear: 645, 647
  • Front Wheel Size: 19.5 X 6
  • Rear Wheel Size: 19.5 X 6
  • Spare Wheel Size: , Full-Size
  • Front Wheel Material: Forged Aluminum
  • Rear Wheel Material: Forged Aluminum
  • Spare Wheel Material: , Steel
  • Steering Type: Re-Circulating Ball
  • Turning Diameter – Curb to Curb: 51.1
  • Brake Type: 4-Wheel Disc
  • Brake ABS System: 4-Wheel
  • Brake ABS System (Second Line): 4-Wheel
  • Disc – Front (Yes or ): Yes
  • Disc – Rear (Yes or ): Yes
  • Front Brake Rotor Diam x Thickness: 15.4
  • Rear Brake Rotor Diam x Thickness: 15.8
  • Drum – Rear (Yes or ):
  • Rear Drum Diam x Width:
  • Fuel Tank Capacity, Approx: 26.5, 40
  • Aux Fuel Tank Capacity, Approx: , 26.5
  • Front Head Room: 40.8
  • Front Leg Room: 43.9
  • Front Shoulder Room: 66.7
  • Front Hip Room: 62.5
  • Second Head Room: 40.4
  • Second Leg Room: 43.6
  • Second Shoulder Room: 65.9
  • Second Hip Room: 64.7
  • Wheelbase: 179
  • Length, Overall: 265.2
  • Width, Max w/o mirrors: 80
  • Height, Overall: 82.8
  • Overhang, Front: 38.3
  • Overhang, Rear w/o bumper: 47.2
  • Cab to Axle: 60
  • Cab to End of Frame: 107.2
  • Frame Width, Rear: 34.2
  • Ground Clearance, Front: 8.6
  • Ground Clearance, Rear: 8.6
  • Seventh Gear Ratio (:1): 1.00
  • Eighth Gear Ratio (:1): 0.85
  • Country of Origin: United States Ford Incomplete Vehicle
  • Engine Displacement Units: 6.7, 7.3, 7.3
  • Engine Camshaft: OHV, OHV, OHV
  • Engine Block Type: iron, iron, iron
  • Engine Cylinder Count: 8, 8, 8
  • Engine Valve Count: 2, 2, 4
